Channel Wastewater Grinder

Channel Wastewater Grinder

Pipeline grinder can be installed in variety of diameter pipelines to crush the solids to 8mm*12mm particles.



Product advantage



Operation Principle

  • 1. Solids enter grinders through open channel;
  • 2.Solids pass through cutters for size reduction.;
  • 3.Solids are cut into smaller particles and no threat to downstream equipment.


Materials of Construction

  • Motor: Customized, multiple power options
  • Reducer: Planet gear reducer, good ability to against the load impact
  • Cutter and spacer: heat-treated alloy steel 4130 with surface harden evenly.
  • The hardness is not less than 45~50HRC
  • Shaft: heat-treated alloy steel 4140
  • Mechanicals Seals: Tungsten Carbide faces
  • Housings: Ductile cast iron ASTMA 536
  • Frame: Stainless steel(304,316)

Mechanical Characteristic

  • Ease and Flexibility of Installation
  • ● Adapts to most existing pipelines with little or no modification
  • Mechanical Seals
  • ● Pressure capability up to 6.3kg/cm2;
  • ● No seal flush required and no packing gland to adjust;
  • Manhole
  • ● Manhole diameter: 1.2m
  • ● Wall thickness: 12mm
  • Dual Shaft Design
  • ●Low-speed, high torque grinders handle rags, rocks, wood,clothing, plastics and other debris
  • ●Capable of handling a wider variety of solids than single shafted machine
  • Cutter Options
  • ● Customized cutters with various tooth configurations to meet special application

Control System Function

  • ● PLC Control Cabinet with liquid crystal display, real time monitoring loading
  • ● MODBUS standard field bus Communication interface and remote controllable
  • ● Time adjustment, runtime and failure records query
  • ● Automatic Reversal Function, time and times setting of reversal
  • ● Leakage, Over Capacity, Overheating, Short Out and Lack of phase protection functions
  • ● Authority setting function



Selection table



型號Model 流量Flow Rate(m3/h) 水頭損失Head Drop(mm) 規格尺寸Dimensions(mm) 大約凈重Approximate Net Weight(kg)
A B C
HCC-N80 80 240 1250 180 505 218
HCC-N120 120 340 1362 282 607 230
HCC-N170 170 440 1504 420 745 265
HCC-N240 240 500 1647 586 914 300
HCC-N340 340 550 1720 730 1058 330
HCC-N480 480 600 1885 880 1208 356
HCC-N670 670 750 2017 1030 1358 389
HCC-N920 920 900 2169 1180 1508 420
